Products Category
KNX LCD Touch Screen Panel
KNX LCD Touch Screen Panel
KNX LCD multi-function touch panel with exquisite aluminum alloy frame could arbitrarily defined lighting, curtains, dimming, RGB dimming, AC, floor heating, fresh air, HAVC, background music, power query, air quality control, timing management, scenes management etc.

Model: TS0401
Bus Voltage: 21-30V DC
Auxiliary Power Supply Voltage: 24 V DC
Bus Current: < 12 mA
Auxiliary Current: < 60mA
Bus Power: < 360mW
Dimension (H x W x D): 86X86X29 mm

D8B / D8 Knob Thermostat
D8B / D8 Knob Thermostat
The KNX Knob Thermostat can control air conditioning, floor heating and fresh air.

Series: D8B /D8
Power: 24V DC
Material: Metal Surface / Plastic
Button Type: Push Button with Knob
Dimension: 86mm×86mm
Installation Method: UK Square Wall Box
Color: D8B (Brushed Black / Brushed Grey / Brushed Champagne / Spray White / Spray Black / Spray Grey / Spray Champagne
D8 (Black / Grey / Champagne)

Z8 Knob Thermostat
Z8 Knob Thermostat
The KNX Knob Thermostat can control air conditioning, floor heating and fresh air.

Series: Z8 Series
Power: 24V DC
Material: Full Metal
Button Type: Push Button with Knob
Dimension: 86mm×86mm
Installation Method: UK Square Wall Box
Color: Frosted Black / Frosted Grey / Frosted Champagne / Frosted Silver
Brushed Grey / Brushed Champagne / Spray Black / Spray White / Spray Grey

Z-WK6 KNX Smart Thermostat
Z-WK6 KNX Smart Thermostat
Z-WK6 KNX Screen Touch Thermostat can control air conditioning, floor heating and fresh air.

Series: Z-WK6
Power: 24V DC
Material: Acrylic
Button Type: Touch Panel
Dimension: 86×86mm
Installation Method: UK Square Wall Box
Color: Spray White / Spray Black / Spray Grey / Spray Champagne
Brushed Balck / Brushed Grey / Brushed Champagne

KNX Curtain Actuator
KNX Curtain Actuator
Model: MC0406
Main Input: 200~240V
KNX Bus Input: 21-30VDC
KNX Bus Current: ≤10mA
Bus Power: ≤ 2.3W
Shell Material: PA66
Size (mm): 145mm x 90mm x 64mm

KNX 0-10 V Dimming Actuator
KNX 0-10 V Dimming Actuator
Model: MD041601; MD061601
Main Input: 200~240V AC; Main Output: 0-10V
0-10V Output: Output of each circuit≤ 40mA
KNX Bus Input: 21-30VDC
KNX Bus Current: ≤12mA; Bus Power: ≤ 2.7W
Shell Material: PA66
Size (mm): 145mm x 90mm x 64mm 4/6 Circuits

KNX Multi Protocol Control Gateway
KNX Multi Protocol Control Gateway
Model: MG0201
Main Input: 12~24 VDC
KNX Bus Input: 21-30VDC
KNX Bus Current: ≤10mA
Bus Power: ≤ 2.3W
Shell Material: PA66
Size (mm): 145mm x 90mm x 64mm

KNX BUS Auxiliary Power Supply
KNX BUS Auxiliary Power Supply
Model: MP6402
Main Input: 100-240VAC; 50/60Hz
KNX Bus Output: 1 circuit with reactor, 21-30VDC
Auxiliary Power Output: 1 without reactor, 30VDC
Nominal Output Current: I₁+I₂≤640mA, short circuit protection
Shell Material: PC
Size (mm): 72mm*90mm*64mm

KNX Line Coupler
KNX Line Coupler
Model: MG0601
KNX Bus Input: 21-30VDC
KNX Bus Current: ≤12mA
Bus Power: ≤ 360mW
Shell Material: PA66
Size (mm): 38mm x 90mm x 64mm
